It checks for a high signal from the button, then checks to see if the mval is 0 or 1 (1 being off, 0 being on) if its on the next case turns the LED set off, and if I put more code from it in, the next if would have checked for mval = 0 and then turned the LEDs on. Its sloppy but it works something like this: Also I have all the bracket pairs color coded and an initial if else case in there to show that you can group larger if statements under others to dynamically search, or set variables. The Orange ones are just a show of repeated patter, giving each if statement a bracket group. The green ones are the "capsule" for your if statement, the red ones being the one for your void loop. So you never write your if statements without their own set pf Try it out for yourself =D // Traffic light code designed by Marquez Santos! (on facebook) LEDS on pins 5 -7 control traffic in East and West directions LEDs on pins 13-11 control traffic in North and South directions

Here is my 2 lane traffic light system (took hours to complete) Try it for yourself =) // Traffic light code designed by Marquez Santos! (on facebook)ĭigitalWrite(13, HIGH) // Turns LED on pin 13 onĭelay(2500) // LED on pin 13 remains on for 5 secondsĭigitalWrite(13, LOW) // Turns LED on pin 13 offĭigitalWrite(12, HIGH) // Turns LED on pin 12 onĭelay(2500) // LED on pin 12 remains on for 5 secondsĭigitalWrite(12, LOW) // Turns LED on pin 12 offĭigitalWrite(11, HIGH) // Turns LED on pin 11 onĭelay(2500) // LED on pin 11 remains on for 5 secondsĭigitalWrite(11, LOW) // Turns LED on pin 11 offĭouble lane code below // Traffic light code designed by Marquez Santos! (on facebook)

#ARDUINO TRAFFIC LIGHT WITH TIMER TRIAL#

This morning I started familiarizing myself with coding and decided "why not make my own?".Īfter an hr or 2 (lost count) of trial and error, I finally came up with this short traffic light LED code. I received my duemilanove yesterday in the mail and she is indeed a beauty. I'm a new member to the arduino community.
